At EGA Products, safety and quality are two of our top requirements in manufacturing a product.  That is why all of our products are OSHA compliant, with some products being CAL-OSHA complaint, ANSI compliant, and IBC complaint.  It is always good idea to check with your safety department and local safety codes when it comes to industrial products.  If you are ever in question if one of our products meets a certain code or can be manufactured to meet certain codes, contact us.OSHA Rolling Ladder Requirements Code 1910.23

OSHA Standards for Ladders

The OSHA code that ladders falls under is OSHA 1910.23 – Ladders. There are five different sections that fall under this code labeled a to e. Section (e) of OSHA 1910.23 relates to rolling ladders, all codes relating to this section are listed in the table below.

OSHA Rolling Ladder Requirements – 1910.23(e)

OSHA Number Definition
1910.23(e) Rolling ladders, mobile ladder stands and platforms
1910.23(e)(1)(i)* Rolling ladders must have a step width of at least 16 inches (41 cm)
1910.23(e)(1)(ii) Steps and platforms must be slip resistant either by design/construction or secondary process/operation
1910.23(e)(1)(iii) Stands and platforms are capable of supporting at least 4x their maximum intended load
1910.23(e)(1)(iv) Casters or wheels under load must support 4x the maximum intended load, plus their proportional share of the ladders/unit’s weight
1910.23(e)(1)(v) Unless otherwise specified, rolling ladders and platforms with a top step height of 4 feet (1.2 m) or above, must have handrails with a vertical height of 29.5 inches (75 cm) to 37 inches (94 cm), measured from the front edge of a step
(Removable gates or non-rigid members, such as chains, may be used instead of handrails in special use applications)
1910.23(e)(1)(vi) The maximum work-surface height of mobile ladder stands and platforms does not exceed four times the shortest base dimension, without additional support. For greater heights, outriggers, counterweights, or comparable means that stabilize the mobile ladder stands and platforms and prevent overturning must be used
1910.23(e)(1)(vii) Mobile ladder stands and platforms that have wheels or casters are equipped with a system to impede horizontal movement when an employee is on the stand or platform
1910.23(e)(1)(viii)* No rolling ladder can move while you or an employee is on it
1910.23(e)(2) Rolling Ladder Stand Design Requirements. The employer must ensure:
1910.23(e)(2)(i) Steps are uniformly spaced and arranged, with a rise of not more than 10 inches (25 cm) and a depth of not less than 7 inches (18 cm). The slope of the step stringer to which the steps are attached must not be more than 60 degrees, measured from the horizontal
1910.23(e)(2)(ii) Rolling ladders with a top step height above 10 feet (3 m) have the top step protected on three sides by a handrail with a vertical height of at least 36 inches (91 cm); and top steps that are 20 inches (51 cm) or more, front to back, have a midrail and toeboard.
(Removable gates or non-rigid members, such as chains, may be used instead of handrails in special-use applications)
1910.23(e)(2)(iii) The standing area of a rolling ladder is within the base frame
1910.23(e)(3) Platform Design Requirements. The employer must ensure:
1910.23(e)(3)(i) Steps of mobile ladder stand platforms meet the requirements of paragraph (e)(2)(i) of this section. When the employer demonstrates that the requirement is not feasible, steeper slopes or vertical rung ladders may be used, provided the units are stabilized to prevent overturning;
1910.23(e)(3)(ii) Rolling ladders with a platform height of 4-10 feet (1.2-3 m) have, in the platform area, handrails with a vertical height of at least 36 inches (91 cm) and midrails; and
1910.23(e)(3)(iii) All ladder stand platforms with a platform height above 10 feet (3 m) have guardrails and toeboards on the exposed sides and ends of the platform
1910.23(e)(3)(iv) Removable gates or non-rigid members, such as chains, may be used on mobile ladder stand platforms instead of handrails and guardrails in special-use applications



Along with knowing the OSHA codes for rolling ladders, knowing the types of treads on rolling ladders, and knowing how to pick out a rolling ladder are crucial in the buying process. Rolling stairs OSHA codes are followed strictly when manufacturing all of our rolling stairs/ladders.
