Shop EGA’s Online StoreWhen researching industrial equipment such as industrial fixed ladders, one should take into account how the product is manufactured and if it meets all safety codes required. At EGA Products, Inc., we manufacture all our products to follow either OSHA requirements, CAL-OSHA, IBC, or ANSI safety codes. Fixed ladders fall under OSHA 1910.23 – Ladders and OSHA 1917.118 – Fixed Ladders. OSHA standard 1910.23 deals with an assortment of ladders such as portable ladders, rolling ladders, fixed ladders, cage ladders and mobile ladder stands. If you have any questions about whether or not a product meets a certain code, please contact us. Read more below to see the standard fixed ladder OSHA safety requirements. Updated for the year 2024.
OSHA Standard for Fixed Ladders
Vertical fixed ladders are known to be dangerous and cause many injuries each year. OSHA has a few different subparts relating to ladder safety and fall protection. The exact subpart for fixed ladders is OSHA 1910.23(d) – Fixed Ladders. We will be focusing on subpart 1910.23(d) as it pertains to what the employer must ensure and few other codes that are should be noted.
OSHA Fixed Ladder Requirements – 1910.23(d) | |
| OSHA Number | Definition |
| 1910.23(d) | Fixed ladders. The employer must ensure: |
| 1910.23(d)(1) | Fixed ladders are capable of supporting their maximum intended load |
| 1910.23(d)(2) | The minimum perpendicular distance from the centerline of the steps/rungs, grab bars, or both, to the nearest permanent object in back of the ladder is 7 inches, elevator pit ladders is the only exception at 4.5 inches |
| 1910.23(d)(3) | Grab bars do not overhang on the climbing side beyond the rungs of the ladder they are on |
| 1910.23(d)(4) | The handrails or extensions of walk-through or sidestep ladders extend at least 42 inches above the top of the access level or landing platform provided by the ladder. For parapet ladders, the access level is determined by: |
| 1910.23(d)(4)(i) | The roof, if the parapet is cut to allow a walk-through the parapet; or |
| 1910.23(d)(4)(ii) | The top of the parapet, if the parapet is continuous |
| 1910.23(d)(5) | For walk-through fixed ladders with the steps/rungs omitted from the extensions. The side rail extensions are flared to provide not less than 24 inches and not more than 30 inches of clearance. If there is a fixed ladder safety system provided, the maximum clearance must not exceed 36 inches |
| 1910.23(d)(6) | For side-step ladders, the side rails, rungs, and steps must be continuous in the extension |
| 1910.23(d)(7) | Grab bars/handrail extension extend 42 inches above the access level or landing platforms |
| 1910.23(d)(8) | The minimum size (cross-section) of grab bars is the same size as the rungs of the ladder |
| 1910.23(d)(9) | When a fixed ladder ends at a hatch, the hatch cover: |
| 1910.23(d)(9)(i) | Opens with enough clearance to provide easy access to or from the ladder; and |
| 1910.23(d)(9)(ii) | Opens at least 70 degrees from horizontal if the hatch is counterbalanced |
| 1910.23(d)(10) | Individual-rung ladders are made to prevent the employee’s feet from sliding off the two ends of the rungs |
| 1910.23(d)(11) | Fixed ladders having a pitch more than 90 degrees from the horizontal are not used |
| 1910.23(d)(12) | The step-across distance from the centerline of the rungs or steps is: |
| 1910.23(d)(12)(i) | For walk-through ladders, not less than 7 inches and not more than 12 inches to the nearest edge of the structure, building, or equipment accessed from the ladders |
| 1910.23(d)(12)(ii) | For side-step ladders, must be between 15 inches and 20 inches to the access points of the platform edge |
| 1910.23(d)(13) | Fixed ladders that do not have cages or wells have: |
| 1910.23(d)(13)(i) | A clear width of at least 15 inches on each side of the ladder centerline to the nearest permanent object; and |
| 1910.23(d)(13)(ii) | A minimum perpendicular distance of 30 inches from the centerline of the steps or rungs to the nearest object on the climbing side. When unavoidable objects are in the way, the minimum clearance is reduced to 24 inches. Deflector plates for head hazards must be installed if this is the case |
Please be aware that section 1910.28 establishes the employer’s duty to provide fall protection for employees on fixed ladders, and section 1910.29 states the criteria for fall protection systems for fixed ladders.
Other Important OSHA Ladder Codes to Remember | |
| OSHA Number | Definition |
| 1910.23(b)(4) | Clear width between rungs/steps is a minimum 16 inches* |
| 1910.28(b)(9)(i) | For fixed ladders that are more than 24 feet above the ground or lower level, the employer must ensure: |
| 1910.28(b)(9)(i)(A) | Existing fixed ladders. Every fixed ladder installed before November 19, 2018 is equipped with a personal fall arrest system, ladder safety system, cage, or well |
| 1910.28(b)(9)(i)(B) | New fixed ladders. Every fixed ladder (more than 24 above the ground/lower lever) installed on and after November 19, 2018, is equipped with a personal fall arrest system or a ladder safety system |
| 1910.28(b)(9)(i)(C) | Replacement. When a fixed ladder, cage, or well, or any portion of a section thereof, is replaced, a personal fall arrest system or ladder safety system is installed in at least that section of the fixed ladder, cage, or well where the replacement is located; and |
| 1910.28(b)(9)(i)(D) | Final deadline. On and after November 18, 2036, all fixed ladders are equipped with a personal fall arrest system or a ladder safety system |
| 1917.118(e)(1) | Fixed ladders more than 20 feet in height must have a cage, well, or ladder safety device |
If there is any other questions or concerns you are curious about, feel free to fill out a contact form. EGA manufactures standard fixed cage ladders and vertical fixed ladders on certain models up to 24 feet. We do not provide or sell personal fall arrest systems, nor can we recommend one for you to buy.
EGA Fixed Ladders
At EGA Products, we have a wide variety of industrial fixed ladders. These fixed ladders include vertical wall mount ladders, caged ladders, uncaged ladders, walk-through dock ladders, side-step dock ladders, crossover ladders, and small two step wall mount ladders. All products from EGA are proudly made in the USA at our Wisconsin or North Carolina locations. Reach out to us at 800-937-3427 or fill out a contact form if you have any questions.
Looking to verify questions relating to a wall mounted fixed ladder.
1) Looking to verify OSHA requirements are met for a commercial application. Intended use is for reaching high shelves along a restaurant backbar. Ladder would be attached to a concrete wall/column with shelving on either side.
2) Room behind bar is minimal; ideally looking for straight vertical run; can accommodate an 5-10 deg angle is required.
3) Looking for additional info on depth of wall mount brackets for approx. 9′-0″ height ladder
Hello, our fixed ladders meet OSHA and ANSI requirements and the depth of the wall mount brackets to the ladder is 7″. Fixed vertical ladders have a straight vertical run. You would have to double check for any local and state building codes as well. Our ladders aren’t food-grade stainless or “wash down” so that might be another factor to look into as well.
how much are your ladders? I need a ladder like the first one of the five on this page. with the cage. about 15′ high. im making a bid tomorrow and need some kind of an idea. thank you
Please fill out a request for quote by visiting this page and selecting the best ladder for you. https://www.egaproducts.com/products/fixed-vertical-cage-ladders
i’m Looking for a ladder that meets our need which is to get access to a platform which is 51 ft height.
No sure the specs o standart needed to comply with the regulations
It would be best to read up on OSHA codes 1910.23, 1910.28, and 1910.29. Also check with your local building codes and local OSHA representative. We only make ladders up to 24 feet as anything above needs a personal fall arrest system.
